Vox Adio Air Guitar Amp AMPS/FX

Vox Adio Air GT Guitar and Audio Amplifier

The ultimate multi-purpose 50W amp & audio solution for the modern musician.

• Powerful 50W high-output amp.
• 2 x 3” speakers for true stereo sound.
• Proprietary chassis design ensures powerful and clear sound.
• Eight hours of continuous operation using eight AA batteries.
• Lightweight design of only 2.9 kg
• VOX’s proprietary VET modeling technology perfectly reproduces the response of each amp.
• A wide range of up to 23 different realistic amp models. (Adio Air GT)
• A wide range of up to 17 different realistic amp models. (Adio Air BS)
• Up to 19 types of high-quality effects.
• Tone Room software takes full advantage of the Adio’s capabilities.
• Bluetooth MIDI support allows parameters to be controlled wirelessly.
• Delivers excellent, room-filling sound when used as an audio playback device.
• Bluetooth audio support lets you wirelessly stream your favorite songs.
• AUX input jack allows convenient jam sessions.
• Acoustage function generates a virtual “surround-sound” effect.
• Audio equalizer equipped with a bassilator circuit that generates a rich low-frequency range.
• Noise reduction when using high-gain sounds.
• Auto tuner that also supports dropped tunings.
• USB interface that lets you switch between three different routings.
• Bundled with JamVOX III.

50W amp that outperforms its size

Though it is compact and lightweight, the Adio is equipped with a high-wattage power amp boasting 50W of stereo output. It delivers a startling sense of volume that outperforms other amps in its class. The 2 x 3”stereo speaker system makes for an incredible playing and listening experience. Because it is capable of such high-output, the Adio is equally effective as an at-home practice amp as it is a full-fledged performing amp.

Proprietary chassis design ensures powerful and clear sound

Adio provides both the hard-hitting cabinet resonance of a guitar/bass amp, and the high fidelity of home audio speakers. Thanks to new concepts used in its cabinet structure, the multi-purpose Adio excels in both scenarios. It features a bass reflex structure that delivers a sound density far exceeding the unit’s size, and an inner box that emanates the sense of spatiality and depth you expect from stereo speakers. The speakers are contained in a sophisticated slant-body design, creating powerful and high-quality sound that shines for both performance and listening.

A divided cabinet design

To prevent unwanted cabinet resonance, the inner box that secures the speakers is completely separated from the rear cabinet. Additionally, the inner box separates L and R into independent spaces to produce stereo playback with an enhanced sense of spatiality. Rigidity is enhanced by a chassis design that minimizes parallel surfaces, suppressing unwanted vibration that would adversely affect the quality of the sound.

Honeycomb-structure speaker frame

The front grille uses a honeycomb structure that perforates the speaker area with a set of hexagons. This efficiently maintains strength, yet ensures maximum space. The high ratio of openness means that the speaker is not obstructed, allowing the sound to be clear and direct.

Ported design further enhances low-frequency playback

The bass reflex section uses a flair component that creates a smooth widening at the entry and exit of the cabinet’s port. This minimizes unwanted noise and also enhances the bass reflex efficiency to further boost the low-frequency playback.

Unique shape allows for enhanced listening experience

The unique slanted design of the Adio allows you to position it with the speakers pointing diagonally upward so that the output reaches your ears directly even at short distances. This means that you can enjoy always performing or listening in the sweet spot. The chassis is designed to minimize parallel surfaces, delivering a smooth sound that suppresses any internal resonances.

A handle that’s integrated with the cabinet

With a recessed slot built into the back of the cabinet, the Adio combines sleek looks with convenient portability.

VOX’s proprietary VET (Virtual Element Technology) modeling technology

The Adio uses VET (Virtual Elements Technology). Instead of simply imitating the output sound of the original amp, VET meticulously models even its components and circuit design. Without relying on the ears of individual engineers, and without being influenced by the condition of a specific amp unit, VET perfectly reproduces the characteristics of the original amp. And it’s equipped with a highperformance DSP to ensure high sound quality.

In addition, the distortion algorithms on the Adio Air GT have been refined, allowing you to enjoy the ultimate touch response that reflects your finest picking nuances without obscuring them.

Up to 23 types of realistic and wide-ranging amp models (Adio Air GT)

The total of 11 built-in amp models includes VOX’s legendary AC30 as well as a variety of high-gain and clean amps. The models have been carefully tuned to take full advantage of the compact Adio’s potential, so that all of them are truly usable high-quality amp models. By using the Tone Room software, you can choose from a total of 23 types of amp models. With just this single unit, you can enjoy a variety of amp sounds ranging from classic vintage amps to costly boutique amps.

A full complement of effects is also provided: four modulation-type effects, such as chorus and tremolo (FX1) and four ambience-type effects, such as delay and reverb (FX2), are built in. Appropriately for the Adio with its stereo speakers, it is also equipped with highquality stereo effects, and you can simultaneously use a total of three effects including noise reduction. As with the amp models, using the Tone Room software lets you choose from a total of 19 types of effect: 11 for FX1 and 8 for FX2.

Via Bluetooth, via USB Tone Room software draws out the essence of the Adio

Tone Room editor/librarian software is provided, which lets you choose from an even richer selection of amp models and effects, and also lets you take advantage of the Adio’s full potential by customizing detailed parameters and audio EQ settings. Up to eight customized amps and effects can be saved in the Adio. Tone Room runs on multiple platforms: Windows, Mac, iOS, and Android.

The Adio Air additionally supports Bluetooth MIDI, so you can control parameters wirelessly, allowing you to effortlessly design your sound using your favorite device.

Via Bluetooth, via AUX Superb performance as a speaker for listening The Adio performs equally as well as an audio speaker, delivering pure, analog-quality sound. With a high output of 50W, the Adio gives you an extremely clear sound that’s well balanced from the low to the high ranges.

The Adio Air also supports Bluetooth audio. You can connect it to your computer or smartphone via Bluetooth, and use it to play back your favorite music from either device. Whether for personal enjoyment in your living room or bedroom, for playing background music in a store, or for outdoor use, you can enjoy the ultimate listening experience in a variety of situations that take advantage of this unit’s high output power, battery operation, and compact size.

Of course, an AUX input jack is also provided. This is a convenient way to enjoy jam sessions while you listen to your favorite songs.

Experience virtual surround with Acoustage

The Adio is equipped with “Acoustage” virtual surround technology. Simply by turning on this function, you can obtain a startlingly wide stereo effect. This function is particularly impressive when used in conjunction with a stereo effect, giving you a guitar/bass amp that lets you feel as though you’re on a wide stage, or experience an unmatched surround space as if you’re inside a lavish multichannel audio speaker setup.

Multiple functions to support the player

Audio equalizer

The unit provides four preset EQ settings for you to select as desired. Additionally, you can use the Tone Room software to make detailed adjustments to each frequency band of the graphic equalizer. Furthermore, you can use Tone Room to make settings for VOX’s original “Bassilator” circuit which covers the low-frequency range not reached by the EQ, letting you enjoy
ultra-low sounds that you would not expect from a unit of this size. Up to four of the EQ settings you’ve made can be stored as user settings in Tone Room.

Noise reduction

A noise reduction function is provided to reduce unwanted noise when using high-gain sounds. This can be adjusted in five steps.

Auto tuner that also supports dropped tunings

The Adio also provides a tuning function that’s indispensable for guitar/bass playing. The tuner also supports half-down tuning mode.

USB audio interface

Since the Adio is equipped with a USB port, you can connect it to your computer or tablet and use Tone Room software, or use the Adio as a USB audio interface to record and play back your performance. The Tone Room software lets you switch between three types of routing: monaural/stereo recording or re-amp.

JamVOX III modeling software is bundled (Adio Air GT)

Since JamVOX III modeling software is bundled, you can easily enjoy playing guitar on your PC. You can take advantage of the GXT function that lets you cancel or extract/emphasize a specific part from an existing song; you can also use the music player function to play back a loop from a song that you’re learning or practicing, and even change its tempo. ASIO drivers are supported, so you can also record and play back via software other than JamVOX III, such as a DAW or guitar amp simulator.
